288-3456F Rollable Ribbon Jelly-Free FRP Fiber Optic Cable, SM G657.A2 200µm, 250µm, LadonX™

The Hermesys LadonX™ Rollable Ribbon fiber optic cable is a high-density, jelly-free cable built around 12-fiber rollable ribbons, supporting 288 to 3456 fibers in a single lightweight cable. The rollable ribbon design maximizes packing density while staying compatible with mass-fusion splicing, and its FRP strength member with a black LSOH sheath keeps the construction lightweight and non-metallic for structured cabling, telecom backbone, and indoor/outdoor FTTx deployments.

Key Features and Benefits

• 12-fiber rollable ribbon design with 250 µm fiber coating
• High-density fiber counts from 288 to 3456, scalable via ribbon count (24–288)
• Jelly-free (dry) construction with water-blocking yarn and tape
• FRP strength member for a lightweight, non-metallic, corrosion-resistant build
• Black LSOH outer sheath for low-smoke, halogen-free fire safety
• 2 ripcords for fast, clean sheath removal
• High tensile and crush performance — 2700 N (short-term) / 810 N (long-term) tensile, 2200 N/100 mm (short-term) / 660 N/100 mm (long-term) crush
• Wide operating range from -40°C to +70°C (storage), -20°C to +60°C (installation)

Typical Applications

• Structured Cabling Systems
• Telecom Backbones
• Indoor and Outdoor Networks
• FTTx Deployments

Reference Standard

• IEC 60794
• IEC 60332-1 (Fire Retardant)
• IEC 60754-1, IEC 60754-2, IEC 61034-2 (LSOH)
