Hollow-core fiber (HCF) is an optical fiber that guides light through a central channel of air instead of solid glass. Because light travels about 50% faster in air than in silica, hollow-core fiber cuts latency by roughly one third compared with standard single-mode fiber. In 2025, researchers reported attenuation below 0.1 dB/km, lower than any solid-core fiber, which moved HCF from the lab into data centre and network deployments.
In this guide: how hollow-core fiber guides light, how the main types compare, how much latency it saves, how low loss has fallen, and what to consider before deploying it.
Hollow-core fiber at a glance
| Standard single-mode fiber (G.652) | Hollow-core fiber (anti-resonant) | |
|---|---|---|
| Core | Solid silica glass | Air |
| Light travels at | About 2/3 of the speed of light in vacuum | Close to the speed of light in vacuum |
| Latency | About 4.9 µs per km | About 3.3–3.4 µs per km |
| Typical loss | About 0.14–0.2 dB/km at 1550 nm | Below 0.1 dB/km in the best 2025 results |
| Nonlinearity and dispersion | Moderate | Very low |
| Splicing and connectors | Standard tools | Needs specific splicing recipes, bridge fibers or HCF connectors |
What is hollow-core fiber?
A hollow-core fiber has three parts: an air-filled core, a glass microstructure around it that traps the light, and the usual protective coating and buffer. The core can also be filled with a specific gas or held under vacuum for sensing and laser applications.
In conventional fiber, light stays in the core by total internal reflection, which only works when the core has a higher refractive index than the cladding. Air has a lower refractive index than glass, so a hollow core cannot rely on total internal reflection. Instead, the cladding is engineered so that light at the operating wavelengths cannot escape.
How hollow-core fiber guides light
Photonic bandgap guidance
The first practical hollow-core fibers used a photonic crystal cladding: a periodic honeycomb of tiny air holes. The periodic structure creates a photonic bandgap, a range of wavelengths that cannot propagate through the cladding, so light in that range stays in the hollow core. These fibers proved the concept but have narrow bandwidth, and light interacting with the many glass surfaces kept their loss well above that of standard fiber.
Anti-resonant guidance
Modern low-loss hollow-core fibers use anti-resonant guidance. The core is surrounded by a ring of thin glass tubes or membranes. When the wall thickness is chosen correctly, light reflecting from each membrane interferes destructively in the cladding, so it is pushed back into the core instead of leaking out. Because only a few thin glass walls touch the light, very little of the signal travels in glass.
Designs have evolved from single-ring tubular fibers to nested anti-resonant nodeless fibers (NANF) and double nested designs (DNANF). Each added layer of nested tubes further reduces leakage, which is why loss has fallen so quickly in recent years.
Hollow-core fiber types compared
| Type | How it guides light | Bandwidth | Main uses |
|---|---|---|---|
| Hollow-core photonic bandgap fiber (HC-PBGF) | Photonic bandgap in a periodic air-hole cladding | Narrow | Early research, gas sensing |
| Single-ring tubular anti-resonant fiber | Anti-resonance from one ring of glass tubes | Wide | High-power laser delivery, short links |
| Nested anti-resonant nodeless fiber (NANF / DNANF) | Anti-resonance from nested tubes | Very wide | Low-latency telecom and data centre links |
Hollow-core photonic bandgap fiber (HCPBF). The periodic microstructured cladding creates photonic bandgaps that stop specific wavelengths from entering the cladding, so their energy stays in the hollow core. This keeps transmission loss low within the bandgap, but the usable wavelength window is narrow.
Nested anti-resonant nodeless fiber (NANF). The cladding contains tubes nested inside larger tubes, and light travels almost entirely in the air core. The tubes do not touch each other, so there are no "nodes" where light can leak, which keeps loss low. NANF supports very wide bandwidth and low-loss transmission, which suits long-distance links between data centres, as well as high-power laser delivery, quantum communication and sensing.
How much latency does hollow-core fiber save?
Light in standard fiber travels through glass with a group index of about 1.47, which works out to about 4.9 µs per kilometre. In hollow-core fiber the light travels almost entirely in air, at about 3.3–3.4 µs per kilometre.
- Per kilometre: about 1.5 µs saved one way, or about 3 µs round trip.
- Over 100 km: about 0.15 ms saved one way, or 0.3 ms round trip.
- Overall: light moves about 47% faster, so latency falls by about one third.
That means a hollow-core link can be about 50% longer than a standard fiber link and still deliver the same latency. For data centre operators, this widens the area in which separate sites can work together as one low-latency region.
How low is hollow-core fiber loss today?
For most of its history, hollow-core fiber lost more signal per kilometre than standard fiber, which limited it to short links. That changed with nested anti-resonant designs: NANF loss had already dropped to 0.28 dB/km by 2020. In September 2025, researchers at the University of Southampton and Microsoft reported a double nested anti-resonant nodeless fiber (DNANF) with attenuation below 0.1 dB/km, published in Nature Photonics. Light in this fiber travels about 33 km before its power halves, compared with about 15 km in standard telecom fiber.
Because so little light travels in glass, hollow-core fiber also offers:
- Low chromatic dispersion: less pulse spreading at high data rates.
- Very low nonlinearity: higher launch power without signal distortion.
- Wide usable spectrum: more wavelength bands available than in conventional fiber.
- Low thermal sensitivity: latency changes less with temperature, which helps timing and synchronisation.
Where hollow-core fiber is used today
- Data centre interconnect and AI networks. Microsoft acquired hollow-core specialist Lumenisity in 2022 and in 2024 announced plans to deploy 15,000 km of hollow-core fiber across its Azure network. It is scaling up production with Corning and Heraeus Covantis.
- Financial trading. In 2021 euNetworks deployed hollow-core fiber cable between a London data centre and the London Stock Exchange, cutting round-trip latency by about 3 µs per kilometre.
- High-power laser delivery. Because the light travels in air, hollow-core fiber can carry high peak power with good beam quality and little risk of damage to the fiber.
- Gas sensing and spectroscopy. The hollow core can be filled with a gas, giving a long interaction length between light and gas.
What to consider before deploying hollow-core fiber
- Cost and supply. Production is scaling up but is still much smaller than for standard fiber, so plan lead times early.
- Splicing and connectivity. Connecting hollow-core fiber to standard single-mode fiber needs tuned fusion splicing settings, a bridge fiber or a connector designed for hollow-core fiber to match mode fields and keep insertion loss low.
- Installation handling. Keep fiber ends sealed during storage and installation so moisture and dust cannot enter the open core.
- Testing. Hollow-core fiber reflects much less light back than standard fiber, so OTDR settings and test procedures may need adjustment.
- Standards. Industry standards for hollow-core cable and connectivity are still developing, so confirm specifications with your supplier.
LadonX™ hollow-core fiber from Hermesys
The LadonX™ hollow-core anti-resonant fiber uses seamless cladding tubes to deliver stable single-mode operation, low transmission loss and broad bandwidth. Its beam quality makes it well suited to short-distance high-power laser transmission, and its low dispersion supports high-speed optical communication.
Hermesys has worked with equipment manufacturers to test anti-resonant hollow-core fiber under real-world conditions, including tension, compression, moisture exposure and outdoor splicing. In these trials, installed cable loss was maintained at 1 dB/km.
To make hollow-core fiber easier to deploy, Hermesys has optimised an FC connector design specifically for hollow-core fiber. It aligns both fiber ends precisely and couples light into the receiving fiber with minimal loss, supporting larger-scale deployment.
Related: LadonX™ polarization-maintaining photonic crystal fiber
Hermesys also offers LadonX™ large mode area polarization-maintaining ytterbium-doped photonic crystal fiber (PMYBPCF). Its expanded mode field area reduces nonlinear effects, enabling high-peak-power, large-pulse-energy laser transmission, and fiber parameters can be customised in size and shape. Typical uses include polarization multiplexing in optical communication, polarization-sensitive sensors such as Faraday rotation sensors and Sagnac interferometers, and fiber lasers.
Frequently asked questions
Is hollow-core fiber faster than normal fiber?
Yes. Light travels about 47% faster in hollow-core fiber because it moves through air instead of glass. Latency is about one third lower, roughly 3.3–3.4 µs per km instead of 4.9 µs per km.
How much latency does hollow-core fiber save per kilometre?
About 1.5 µs one way, or about 3 µs round trip, for every kilometre of fiber.
What is DNANF?
DNANF stands for double nested anti-resonant nodeless fiber. It is a hollow-core design with two layers of nested glass tubes around the core, and it holds the record for the lowest loss reported in any optical fiber, below 0.1 dB/km.
Can hollow-core fiber be spliced to standard single-mode fiber?
Yes, but it needs adjusted fusion splicing parameters, an intermediate bridge fiber or a connector designed for hollow-core fiber to keep insertion loss and back reflection low.
Is hollow-core fiber commercially available?
Yes. Hollow-core fiber and cable are available for data centre interconnect, low-latency trading links and laser delivery, although volumes are still much smaller than for standard fiber.
References
- University of Southampton ORC – Record low loss hollow core fibre (September 2025)
- Fiber Broadband Association – Microsoft scales up hollow core fiber production (April 2026)
- Lightwave – euNetworks decreases latency with Lumenisity hollowcore fiber cable deployment (April 2021)
- "Preparation and mode conversion application of narrowband hollow-core anti-resonant fiber," Acta Physica Sinica, 71, 134207 (2022).
- Yuan, Jinhui et al., "Study on Hollow-Core Photonic Bandgap Fibers for Visible Light Transmission," Acta Physica Sinica.
